Industrial RS485 Control Panel Android Tablet 10 Inch Embedded Wall Touch Kiosk Support Modbus RTU

Industrial RS485 Control Panel Android Tablet 10 Inch Embedded Wall Touch Kiosk Support Modbus RTU

This Industrial 10 inch android tablett can be customized with different optional configuration based on different clients specific requirement or applications.

The most popular POE ( IEEE 802.3af 48V standard) option,only one ethernet cable can be provided both power and data to this slim 10" android OS rooted touch tablet.

And the adjustable RED/GREEN/BLUE LED light left/right sides indicator can be integrated for clients software redeveloping,free to provide the demo apk and source code.

Also available for NFC reader (13.56MHz Mifare MF1 IC S50 CARD), front Proximity sensor & Ambient Light Sensor and Serial communication port RS485/RS232 as well as GPIO.

Advantages:

• Android 6.0.1 OS rooted,built in Google Play Store
• Auto boot up when power supplies
• POE Ethernet RJ45 port ( IEEE 802.3 af 48V standard POE) or DC IN 9-24V
• On wall surface(23 degree angled), inwall flush mounting,glass wall mounting
• Programmable physical buttons(function A button)
• free to provide the customized splash screen with your company logo

Back Interface:

• DC IN (9-24V)

• RJ45

• USB 2.0

• Optional for one group RS232/RS485/GPIO

• Micro USB port(upgrading/flashing need)

Network:

• WLAN(WiFi 802.11b/g/n)
• LAN Ethernet RJ45 port
• Bluetooth V4.0 support Bluetooth Low Energy (BLE)

​
